Pre Embedded Ftth 3.0mm Sc Upc Fast Connectors Assembly

گواهی
چین Shenzhen CY COM Product Co., Ltd گواهینامه ها
چین Shenzhen CY COM Product Co., Ltd گواهینامه ها
The quality of fiber optic pigtail is very good and have good package,will cooperate with you next time.

—— خوزه آلوز

Your products are good quality and lead time is short,will purchase from you next time.

—— آندری جوان

The MPO patch cord is good loss data and have stable performance, the most important is your price is lower than other ,and service in time.

—— ارتش باردو

I have bought the FTTH box several times from you,every time can be delivered on time and the quality is very good

—— رنگ سبز

کیفیت خوب و خدمات خوب. شما یک شریک قابل اعتماد هستید

—— دان هیکس

به همان قیمت، فیبر پچ فیبر بهتر از دیگران است.

—— دانی استیون

فقط در زمان کشتی، به دنبال همکاری بعدی.

—— جو بنا

محصولات شما با کیفیت خوب هستند، امیدوارم با شما همکاری داشته باشید.

—— زاهد واسام

چت IM آنلاین در حال حاضر

Pre Embedded Ftth 3.0mm Sc Upc Fast Connectors Assembly

Pre Embedded Ftth 3.0mm Sc Upc Fast Connectors Assembly
Pre Embedded Ftth 3.0mm Sc Upc Fast Connectors Assembly Pre Embedded Ftth 3.0mm Sc Upc Fast Connectors Assembly Pre Embedded Ftth 3.0mm Sc Upc Fast Connectors Assembly Pre Embedded Ftth 3.0mm Sc Upc Fast Connectors Assembly Pre Embedded Ftth 3.0mm Sc Upc Fast Connectors Assembly

تصویر بزرگ :  Pre Embedded Ftth 3.0mm Sc Upc Fast Connectors Assembly

جزئیات محصول:
Place of Origin: Shenzhen China
نام تجاری: CY COM
گواهی: ISO ROSH
پرداخت:
Minimum Order Quantity: 50pcs
قیمت: Western Union, T/T
Packaging Details: PE package bag
Delivery Time: 3-7 days
Payment Terms: T/T, Western Union
Supply Ability: 100K / Week
توضیحات محصول جزئیات
Product name: Fast connectors Color: Blue
Connector: SC UPC Length: 55MM
Insertion cycle: more than 1000 times Application: Telecom networks FTTX CATV
برجسته کردن:

Sc Upc Fast Connectors Assembly,3.0mm Fast Connectors Assembly,3.0mm Ftth Fast Connectors Assembly

,

3.0mm Fast Connectors Assembly

,

3.0mm Ftth Fast Connectors Assembly

Pre Embedded Ftth 3.0mm Sc Upc Fast Connectors Assembly

3.0mm waterproof pre-embedded ftth sc upc quickly assembly fiber optic connectors splice

Description:
1). An fiber optic quick connector terminates the end of an optical fiber, and enables quicker connection and disconnection than
splicing.
2). The connectors mechanically couple and align the cores of fibers so light can pass. Better connectors lose very little light
due to reflection or misalignment of the fibers.

Feature:
1). Low insertion loss
2). High return loss (low amounts of reflection at the interface)
3). Ease of installation
4). Low cost
5). Reliability
6). Low environmental sensitivity
7). Ease of use



Optical Characteristics

Category Specification
Aoolicable for Drop cable.Indoor cable
Fiber mode Single mode or Multi mode
Operation time S About 50(no fiber cut)
Insertion Loss dB ≤0.5
Insertion Loss Typical value dB 0.3
Return Loss dB ≥50
Fastening strength of naked fiber N ≥5
Tensile strength N ≥50
Reusable Time ≥10 times
Operating Temperature -40~+85
On-line tensile strength(20N) dB ΔIL≤0.3
Mechanical durability(500 times) dB ΔIL≤0.3
Drop-off test(drop-off height4m,once per direction,totally 3 times) dB ΔIL≤0.3



Application:
1). CATV
2). Active device termination
3). Telecommunication networks
4). Metro
5). Local Area Networks (LANs)
6). Data processing networks
7). Test equipment
8). Premise installation
9). Wide Area Networks(WANs)

Pre Embedded Ftth 3.0mm Sc Upc Fast Connectors Assembly 0
Pre Embedded Ftth 3.0mm Sc Upc Fast Connectors Assembly 1
Operation

Pre Embedded Ftth 3.0mm Sc Upc Fast Connectors Assembly 2
